MAIN FEATURES · Avinox M2S Motor -150Nm 1300W (Boost mode) / 130Nm 1300W  · Integrated LI-ION 800 Wh battery· Reason Full Carbon frame, Boost, 160mm Wheel travel· Fox 38 Float Factory fork with 160 mm travel· Fox Float X shock· Sram S1000 AXS T-Type 12-speed drivetrain· Shimano XT disc brakes
Technical information
×
Frameset
FrameReason Full Carbon Frame, Alloy shock extension, Full Integratted Battery, 12 x 148 Boost, Megamo ASP, Wheel travel: 160 mm
ForkFox 38 Float Factory E-Bike Optimized, 160mm Travel, Grip X2
ShockFox FLOAT X, Factory Series, Kashima 2pos-adj, Evol LV, 210x55
HeadsetAcros AZA-288R2 ZS56 blocklock 135º
Electronic components
MotorAvinox M2S -150Nm 1300W (Boost mode) / 130Nm 1300W
BatteryAvinox 800 Wh, 35,9V, IP56
DisplayAvinox DP100, 2-inch full-color OLED touchscreen, 800 nits, 326 ppi
ChargerAvinox 12A Fast Charger
Drivetrain
Rear DerailleurSram S1000 EAGLE AXS T-TYPE, 12-Speed
ShiftersSram AXS POD
CranksetSram EAGLE T-TYPE Avinox Chainring 36T 12-Speed, Crankset 165mm
CassetteSram XS 1270 T-TYPE, 10-52T
Brakes
BrakesShimano XT M8220, Hydraulic Disc 4-Piston, RT-CL800 203 mm
Wheels
TiresFront: Maxxis Assegai 29x2.5 DD 3C MaxxGrip / Rear: Maxxis Minion DHR II 29x2.4 DD 3C MaxxTerra
WheelsDT Swiss H 1900 SPLINE, 30mm Tubeless ready Aluminium rim, 370 Ratchet LN 18
Components
HandlebarCarbon Race Face ERA 35x800, Rise 20mm
StemSatori Ursa, 35 x 35 mm
SeatpostFox Transfer Factory Ø31.6 mm S size 150 mm Drop / M size 180 mm Drop / L and XL size 210 mm Drop
SeatFizik Terra Aidon X5, 145 mm
